The MBO MS-12HBME is a 12,000 BTU non-inverter wall-mounted air conditioner designed for residential and light commercial cooling and heating applications. It provides 3.51 kW of rated cooling capacity and 3.546 kW of rated heating capacity, with R410A refrigerant and a single-phase 220–240V power supply. The compact indoor and outdoor units allow for straightforward wall-mounted installation.
Key Features
12,000 BTU cooling capacity
Non-inverter compressor
Cooling and heating
R410A refrigerant
Single-phase 220–240V power supply
3.51 kW rated cooling capacity
3.546 kW rated heating capacity
Compact wall-mounted design
Indoor noise level of 40 dB(A)
Outdoor noise level of 50 dB(A)
Technical Specifications
Brand: MBO
Model: MS-12HBME
Type: Non-Inverter
Cooling Capacity: 3,510 W
Heating Capacity: 3,546 W
Cooling Input Power: 1,140 W
Heating Input Power: 1,148 W
Rated Input Current: 5.3 A
Maximum Input Power: 1,670 W
Maximum Input Current: 7.6 A
EER: 3.08 W/W
COP: 3.08 W/W
Refrigerant: R410A
Refrigerant Charge: 650 g
Maximum Discharge Pressure: 4.2 MPa
Maximum Suction Pressure: 1.2 MPa
Indoor Noise Level: 40 dB(A)
Outdoor Noise Level: 50 dB(A)
Indoor Unit Net Weight: 9 kg
Indoor Unit Gross Weight: 11 kg
Indoor Unit Dimensions: 815 × 290 × 200 mm
Indoor Packaging Dimensions: 880 × 350 × 270 mm
Outdoor Unit Net Weight: 25 kg
Outdoor Unit Gross Weight: 27 kg
Outdoor Unit Dimensions: 718 × 300 × 540 mm
Outdoor Packaging Dimensions: 825 × 380 × 590 mm
Warranty
Compressor Warranty: 5 years
Separate Parts Warranty: 3 years
What’s Included
MBO MS-12HBME indoor unit
MBO outdoor unit
